XenoLidar

Reliable long range object detection and tracking

XenoLidar is a true solid-state LiDAR that meets the highest automotive requirements. The technologically advanced, low power, multi-beam sensor monitors and analyzes a vehicle’s surroundings in real-time.

With a measurement range of 200m and a field-of-view of 30° x 10°, XenoLidar delivers unequalled long range object detection and tracking. The XenoWare software captures superior density 3D point clouds and 2D images, resulting in rich data about the object position, movement and distance to the vehicle. Watch this short animation to see how XenoLidar delivers high density point clouds.

Based on proven semiconductor components, XenoLidar guarantees unequalled performance, operability and reliability.

XenoLidar Highway Metrics

  • Long range detection : up to 200m

  • Data output rate : 50 Hz

  • Field-of-view : 30° x 10°

  • Laser classification : Class 1

  • Resolution : 0,12°

XenoLidar Key Features

  • solid-state LiDAR without moving parts;

  • highly compact sensing device, suitable for integration at various locations on the vehicle, including the windshield;

  • combining 3D point clouds and 2D images with high resolution and superior density;

  • resilient to all light and weather conditions ensuring long life expectancy and high durability.

XenoTrack

Smart LiDAR for precise real-time road measurements

XenoTrack is an effective and reliable short-range 3D road measurement tool that delivers highly precise and accurate data while remaining overly easy to use. XenoTrack is a true solid-state LiDAR with a unique laser projection and triangulation based distance calculation technology that guarantees the most accurate metrology grade data.

Directly mounted on the vehicle in just a few simple steps, the smart LiDAR sensor takes up to 180.000 measurement points per second, at any place and in real-time. The intuitive graphical user interface makes it easy to configure and operate the system.

XenoWare software

The XenoWare software is able to collect a large, dense set of data relatively quickly. The captured data can be used for various calculation and analysis for roads & highways such as road profile analysis, road damage assessment, along with crack patterns and road markings. The data can be viewed in real-time or exported and consulted afterwards for further interpretation and analysis.

XenoTrack is primarily used for road preview for active suspension, 3D road digitization, road classification and small object localization.

XenoTrack Metrics

  • Accuracy of height measurement : <2mm
  • Measurement points : up to 180.000 points / sec
  • Frame rate : 60 Hz

XenoTrack Key Features

  • true solid-state LiDAR without moving parts;
  • versatile sensing device for 3D road digitization, short-range road surface measurement and road quality assessment;
  • laser triangulation sensor that delivers highly accurate metrology grade data.

XenoWare

To implement your vision applications of choice

The XenoWare software uses an open API and provides output formats compliant to automotive standards allowing your development team to use the raw data for developing their own application(s).

  • Data transfer via RS232, CAN or ethernet
  • Pointcloud data storage in STL files
  • Raw geometrical data and intensity maps
  • Replay mode for offline system use and data analysis
  • Parallel video recording for visual documentation
  • Managing the interface to the car's control unit

6 dimensional data

  • Position (X,Y,Z) for all measurement points
  • Intensity information
  • Spot shape
  • Evolution of these parameters in time

System Integration Services

Expertise to make your vision project excel

The XenomatiX engineering team can provide exquisite development and integration services for your optical sensing projects. Services that are offered go from mathematical modeling, to full integration and design services making the sensor adjusted to your application needs.

The XenomatiX vision sensors offer the flexibility to be used on a variety of vehicles and for a multitude of applications. We digitize tracks, rent XenoLidar and XenoTrack systems, run test campaigns, participate in application development or customize the system to optimize your application.

XenomatiX engineers are happy to work together with your experts to find the best solution and to make your application excel.
